Danfoss Solenoid valve EVRC 20 Valve ODF 7/8in Multi 6
Danfoss Solenoid valve EVRC 20 Valve ODF 7/8in Multi 6
Quantity
-
Detail
Solenoid valve, EVRC 20, SOLDER, ODF, 7/8 in, Function: NC. 032L1258. Kv value [m³/h]: 3.600, Manual operation option: No, Packing format: Multi pack.
032L1258 DANFOSS REFRIGERATION Solenoid valve
Gross weight 1.42 Kg Net weight 1.04 Kg EAN 5702428952415 Actuator system [mm] 13.5 mm Ambient temperature -40 - 80 °C Ambient temperature range [°F] [Max] 175 °F Ambient temperature range [°F] [Min] -40 °F Approval UL
EACCoil No Cv value [gal/min] 4.2 gal/min Cv value invert flow [gal/min] 5.8 gal/min Direction Straightway Function NC Inlet connection type SOLDER, ODF Inlet size [in] 7/8 IN Kv value [m³/h] 3.6 m3/h Kv value invert flow [m³/h] 5 m3/h Manual operation option No Max. Working Pressure [bar] 45.2 bar Max. Working Pressure [psig] 655 psig MaxOPD[bar] 10W AC 38 bar MaxOPD[bar] 20W DC 20 bar MaxOPD[bar] coil BJ/BX 38 bar MaxOPD[psi] 10W AC 550 psi MaxOPD[psi] 20W DC 290 psi MaxOPD[psi] coil BJ/BX 550 psi Medium temp. range note Defrost max 130°C/265°F Medium temperature range [°C] [Max] 105 °C Medium temperature range [°C] [Min] -40 °C Medium temperature range [°F] [Max] 221 °F Medium temperature range [°F] [Min] -40 °F MinODP [bar] 0.03 bar MinODP [psi] 0.44 psi MOPD[bar/psi] COIL DEPENDEND Orifice size [mm] 22 mm Outlet connection type SOLDER, ODF Outlet size [in] 7/8 IN Packing format Multi pack Parts Program name EVRC Product Group Solenoid valves Product name Solenoid valve Product type EVRC 20 Quantity per packing format 1 Pcs Refrigerants R1234yf
R1234ze
R125
R134a
R152a
R22
R290
R32
R404A
R407A
R407C
R407F
R410A
R448A
R449A
R450A
R452A
R507
R600
R600aType designation Solenoid valve, Solder Valve operation SERVO-DIAPHRAGM -
